Meeting room 13.3″ Android Tablet Touchscreen with LED bar
- Model No.: MA1330-M
- 13.3 inch IPS panel, 1920x1080 FHD Res
- LED lights design on two side
- CPU: RK3288 / RK3566 / RK3568/ RK3399 for choice
- 10-point capacitive touchscreen
- Network: Wifi, RJ45, Bluetooth
- Mounting type: 75x75mm VESA
- Warranty: 2-years since received monitors
- Specifications
| System | CPU | 1.Quad core cortex A17,1.6G,RK3288 2.RK3566 Quad core cortex A55 3.RK3568 Quad core cortex A55 4.Dual-core A72+quad-core A53,1.8G,RK3399 |
||||||||||||
| RAM | 2GB (4GB optional) | |||||||||||||
| Internal memory | 16GB (32GB / 64GB optional) | |||||||||||||
| Operation system | Android 8.1 / 10 / 11 | |||||||||||||
| Display | Screen | 13.3″LCD IPS panel | ||||||||||||
| Resolution | 1920×1080 @60Hz | |||||||||||||
| Brightness | 300cd/m2 | |||||||||||||
| Contrast | 1000:1 | |||||||||||||
| dot pitch | 0.297×0.297 | |||||||||||||
| Display area | 293.76(H)x165.24mm(V) | |||||||||||||
| Viewing angles | 85/85/85/85(L/R/U/D) | |||||||||||||
| Color | 16.7M | |||||||||||||
| Aspect Ratio | 16:9 | |||||||||||||
| Network | WiFi | 802.11b/g/n | ||||||||||||
| Ethernet | 100M/1000M ethernet | |||||||||||||
| Bluetooth | Bluetooth 4.0 | |||||||||||||
| Interface | SD card slot | SD,Support up to 32GB | ||||||||||||
| Micro USB | Micro USB OTG | |||||||||||||
| USB Host | RK3288: USB Host 2.0 RK3399: USB Host 3.0 |
|||||||||||||
| USB | USB for serial | |||||||||||||
| RJ45 with POE | RJ45 (PoE IEEE802.3at/af) | |||||||||||||
| Earphone | 3.5mm earphone + Micphone | |||||||||||||
| Power | DC power input | |||||||||||||
| Multi-Media | Audio | MP3/WMA/AAC etc. | ||||||||||||
| Video | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 4K | |||||||||||||
| Picture | JPEG, JPG | |||||||||||||
| Other functions | Power consumption | 12W | ||||||||||||
| Speakers | Built-in 2×1.5W speakers | |||||||||||||
| LED Light bar | LED Light bar | |||||||||||||
| Camera | 2.0M/P,Front camera | |||||||||||||
| VESA | 75x75mm wall mounting | |||||||||||||
| OSD language | Multi OSD language | |||||||||||||
| Color | Black / white | |||||||||||||
| Accessories | Adapter | Adapter,12V/1.5A | ||||||||||||
| User manual | One | |||||||||||||
